Grating Stair Treads Dimensions
Stair treads in welded or press-locked steel, made to your specs.
Itemized quote within 24 hours · Free drawing review included
Tread dimensions
Standard Grating Stair Treads Dimensions
Every tread starts as a welded or press-locked parent panel, cut and finished to the going, span and pitch of your flight. Here are the dimension ranges we produce — tread width and length themselves are custom sizes to drawings.
| Parameter | Range |
|---|---|
| Parent panel | Welded (electro-forged) or press-locked |
| Bearing bar | 20×3 mm to 100×8 mm, plain or serrated |
| Bar spacing | 30 / 40 / 60 mm centers · press-locked close mesh to 11 / 11 mm |
| Tread width & length | Custom sizes to drawings |
| End plates | Drilled to your bolt pattern, or plain for site welding |
| Nosing | Checker plate or angle, over serrated or plain tops |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black or hot-dip galvanized (ASTM A123 / ISO 1461) |
How Tread Dimensions Are Measured
-
1
Width — the going
The tread surface from nosing back to the riser. Standard goings run around 250–300 mm; specify yours.
-
2
Length — the span
The distance between your stringers, carried by the bearing bars. Bearing bar size and spacing follow the span and load.
-
3
Pitch angle
The angle of the flight sets how the nosing overhang and end plates sit. Give the angle and we handle the geometry.
Tread tops compared
Serrated vs Plain Stair Tread Tops
Anti-slip behavior comes from geometry, not coating. Here is how the two tread-top choices differ — described as mechanics, with no slip-test claims.
| Dimension | Serrated Top | Plain Top |
|---|---|---|
| Surface geometry | Serrated teeth on the bearing bars | Flat bearing bars, mill edge |
| Grip mechanism | Tooth geometry bites into boot soles | Parallel bar edges underfoot, open mesh sheds water |
| Best suited to | Wet, oily, frost-prone and escape stairs | Dry indoor plant stairs |
| Combines with | Checker-plate or angle nosing | Checker-plate or angle nosing |
| Cost framing | Serration is a rolling step on the bar, not added material | The economical tread top |
| When quoting | State serrated bars | State plain bars |
Not sure which top suits your stairs? Send your drawings — we will spec it inside the 24-hour quote.
Installation
How Grating Stair Treads Are Fitted
Treads arrive dimensioned, drilled and nosed — ready to bolt on or weld down. The parts that stop field problems are the ones we finish before shipping.
Bolted fixing
End plates arrive drilled to your bolt pattern and bolt straight to the stringer. A fixing layout ships with the order.
Welded fixing
Plain end plates can be site-welded to steel stringers when bolting is not wanted — no drilling on site.
Nosing & end plates
The leading-edge nosing marks the stair edge, while end plates carry the fixing — both fitted before shipping.
Custom drilling
Hole positions, slot shapes and bolt sizes are cut to your drawing, so each tread lands on the stair as drawn.
US specifiers reference OSHA 29 CFR 1910.24(c) for fixed industrial stairs. We produce treads to the loads and geometry you specify — installation drawings and a fixing layout ship with every order, and we do not certify your installation.
Custom made
Custom Treads, Cut and Drilled to Your Drawings
Cut to size
Treads are sawn and plasma-cut from parent panels to your width and length — odd sizes and angles are standard.
Banded edges
Open mesh is closed with a band around the perimeter — no snag points, stiffer tread, clean galvanizing line.
Nosing, end plates & holes
Checker-plate or angle nosing at the leading edge, end plates drilled to your bolt pattern — the tread ships ready to install.
In-house weld & press lines
Electro-forging and press-locking under one roof
Certified & tested
Reports on request, MTC with every order
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin
Shipped worldwide, EXW / CIF negotiable
FAQ
Frequently Asked Questions
What dimensions do I need to give for stair treads?
Three numbers define a tread: width (the going), length (the span between your stringers) and the stair pitch angle. Add nosing type and end-plate hole positions, or simply send a sketch. Drawing review is free and included inside the 24-hour quote.
What stair tread size range do you produce?
Treads are cut from welded or press-locked parent panels with bearing bars from 20×3 mm to 100×8 mm at 30 / 40 / 60 mm centers, with press-locked close mesh down to 11 / 11 mm. Tread width and length are custom sizes to drawings — send your going, span and pitch and we quote the exact size.
Can I get a sample before a full order?
Yes — a tread sample ships in 5–7 working days and mass production runs 15–25 working days after drawing confirmation, both including hot-dip galvanizing. Rush production in 10–15 days is possible with a surcharge — ask in your quote.
