Stair Grating
Stair treads, landings & platform grating from one factory. One order, one shipment.
Itemized quote within 24 hours · Free drawing review included
Tread dimensions
Stair Grating Sizes & Dimensions
Stair grating is steel grating stair treads cut from the same bearing-bar panels as our platforms — so a metal grating stair and its landing and walkway grating come from one spec and one shipment. Width and length are custom sizes to drawings.
| Parameter | Range |
|---|---|
| Parent panel | Welded (electro-forged) or press-locked |
| Bearing bar | 20×3 mm to 100×8 mm, plain or serrated |
| Bar spacing | 30 / 40 / 60 mm centers · press-locked close mesh to 11 / 11 mm |
| Tread width & length | Custom sizes to drawings |
| End plates | Drilled to your bolt pattern, or plain for site welding |
| Nosing | Checker plate or angle, over serrated or plain tops |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black or hot-dip galvanized (ASTM A123 / ISO 1461) |
Three Numbers Define a Stair Grating Tread
-
1
Width — the going
The tread surface from nosing back to the riser. Standard goings run around 250–300 mm; specify yours.
-
2
Length — the span
The distance between your stringers, carried by the bearing bars. Bearing bar size and spacing follow the span and load.
-
3
Pitch angle
The angle of the flight sets how the nosing overhang and end plates sit. Give the angle and we handle the geometry.
Tread tops compared
Serrated vs Plain Steel Grating Stair Tops
Anti-slip behavior comes from geometry, not coating. Here is how the two tread-top choices differ — described as mechanics, with no slip-test claims.
| Dimension | Serrated Top | Plain Top |
|---|---|---|
| Surface geometry | Serrated teeth on the bearing bars | Flat bearing bars, mill edge |
| Grip mechanism | Tooth geometry bites into boot soles | Parallel bar edges underfoot, open mesh sheds water |
| Best suited to | Wet, oily, frost-prone and escape stairs | Dry indoor plant stairs |
| Combines with | Checker-plate or angle nosing | Checker-plate or angle nosing |
| Cost framing | Serration is a rolling step on the bar, not added material | The economical tread top |
| When quoting | State serrated bars | State plain bars |
Not sure which top suits your stairs? Send your drawings — we will spec it inside the 24-hour quote.
Installation
Installing Stair Grating on Steel Stringers
Treads arrive dimensioned, drilled and nosed — ready to bolt on or weld down. The parts that stop field problems are the ones we finish before shipping.
Bolted fixing
End plates arrive drilled to your bolt pattern and bolt straight to the stringer. A fixing layout ships with the order.
Welded fixing
Plain end plates can be site-welded to steel stringers when bolting is not wanted — no drilling on site.
Nosing & end plates
The leading-edge nosing marks the stair edge, while end plates carry the fixing — both fitted before shipping.
Custom drilling
Hole positions, slot shapes and bolt sizes are cut to your drawing, so each tread lands on the stair as drawn.
US specifiers reference OSHA 29 CFR 1910.24(c) for fixed industrial stairs. We produce treads to the loads and geometry you specify — installation drawings and a fixing layout ship with every order, and we do not certify your installation.
Custom made
Custom Stair Grating, Cut and Banded to Your Drawings
Cut to size
Treads are sawn and plasma-cut from parent panels to your width and length — odd sizes and angles are standard.
Banded edges
Open mesh is closed with a band around the perimeter — no snag points, stiffer tread, clean galvanizing line.
Nosing, end plates & holes
Checker-plate or angle nosing at the leading edge, end plates drilled to your bolt pattern — the tread ships ready to install.
In-house weld & press lines
Electro-forging and press-locking under one roof
Certified & tested
Reports on request, MTC with every order
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin
Shipped worldwide, EXW / CIF negotiable
FAQ
Frequently Asked Questions
What is stair grating?
Stair grating is steel grating formed into stair treads — the same bearing bars as platform grating, cut to tread size, banded at the edges and fitted with end plates and nosing. It gives open-mesh, anti-slip steps for industrial, plant and escape stairs.
Can steel grating stair treads be made to size?
Yes — tread width and length are custom sizes to drawings. Give us the going, the span between stringers and the pitch angle, or send a sketch, and we cut, drill and band the treads to fit your flight.
What is the lead time for stair grating?
Samples ship in 5–7 working days and mass production runs 15–25 working days after drawing confirmation, both including hot-dip galvanizing. Rush production in 10–15 days is possible with a surcharge — ask in your quote.
Factory-direct quote
Get a Factory Quote in 24 Hours
Send your stair layout for a quote. Engineers reply in 24h, samples in 5–7 days — treads, landings and platform grating in one order and one shipment.
- Five-stage QC, from MTC verification at goods-in to final inspection
- DoC, MTC EN 10204 3.1 and inspection report with every order
- Factory audits welcome — see the lines before you commit
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — we do the rest.
