Serrated Bar Grating
Serrated teeth bite into wet or oily soles. Fewer slips, fewer incidents on site.
Itemized quote within 24 hours · Free drawing review included
Factory-direct, no middlemen
Serrated or plain bar tops from our own welded line
Certified & tested
Reports on request, MTC with every order
Samples in 5–7 days
Production in 15–25 working days
FOB Tianjin
Shipped worldwide, EXW / CIF negotiable
Serrated vs plain vs mixed
One Panel, Three Tops: Serrated, Plain and Mixed
Serrated bar grating is specified at the bar level: the teeth live on the top edge of the bearing bars — the bars your soles actually cross — while the cross bars that hold the panel square stay plain. If you are new to the topic, the serration fundamentals page explains the tooth itself; this page stays one level down, on the bars. Serrated steel bar grating buyers usually choose between three layouts:
| Dimension | Serrated bearing bars | Plain bearing bars | Mixed layout |
|---|---|---|---|
| Where the teeth sit | Top edge of every bearing bar, formed in the bar itself | No teeth — one smooth flat top per bar | Teeth only in the zones that need them |
| Surface under a sole | Many small edges to press against instead of one plane | One continuous plane per bar | Serrated ramps and stairs, plain dry floors |
| Typical zone | Wet, oily, muddy or frost-exposed traffic | Dry interiors, mezzanines, trench covers | One platform spanning several zones |
| Cross bars | Plain twisted square or round, as always | Plain twisted square or round | Plain throughout both layouts |
| Bar range | Any flat bar 20×3 mm to 100×8 mm | Any flat bar 20×3 mm to 100×8 mm | Matching sections and spacing across zones |
| How we quote it | Per drawing, bar section and spacing stated | Per drawing, bar section and spacing stated | One order, panels listed zone by zone |
Not sure where the teeth should go? Send your zone plan — we will spec it inside the 24-hour quote.
Serration mechanics, bar by bar
The Tooth Profile, Described as Geometry
No coefficients, no laboratory claims — just what the bar looks like and why that shape matters underfoot. Three drawings tell the whole story.
1 · One bar, two tops
Same flat bar section, same load duty. The serrated version simply trades the flat top for a row of shallow teeth — the geometry buyers specify as anti-slip.
2 · Teeth on the bearing bars only
Traffic walks across the bearing bars, so that is where the teeth go. The cross bars keep their plain twisted or round profile — they tie the panel together, not underfoot.
3 · Any bar in our range
- Flat bar sections from 20×3 mm to 100×8 mm, serrated or plain
- Bearing bar centers at 30, 40 or 60 mm
- Mixed plain and serrated layouts quoted from one drawing
Why specify serrated bars
Why Buyers Order Serrated Bar Grating From the Mill
Serrated bar built right
The teeth are formed in the bearing bar itself — one piece of steel, not a bonded-on overlay. Same bar, same welded joints, more edges underfoot.
Serrated or plain, any size
Specify by bar section and spacing as usual — the top style is simply another line in the drawing. Any panel we make plain, we make serrated.
Small orders, worldwide, with MTC
Small trial orders welcome; full containers calculated per loading plan. Factory-direct with no middlemen, MTC EN 10204 3.1 on every order.
Applications
Where Serrated Bar Grating Earns Its Keep
Any zone where the walking surface stays wet, oily or frosted is a zone where buyers move from plain to serrated bearing bars — same bar sections, same open mesh.
Wet floors & washdown
Process floors washed down daily, where a film of water sits on every crossing bar.
Ramps & sloped access
Sloped crossings where the sole meets the bar at an angle — the default home of serrated bar grating.
Stairs & landings
Treads with serrated or plain tops, banded edges and end plates — built on the same bearing bars.
Outdoor walkways & platforms
Rain, mud and frost — pair the teeth with hot-dip galvanizing for weather that never dries out.
Specifications
Serrated Bar Grating Specifications
| Parameter | Range |
|---|---|
| Bearing bar | Flat bar 20×3 mm to 100×8 mm, plain or serrated top |
| Bearing bar centers | 30 / 40 / 60 mm |
| Cross bar | Twisted square or round — plain, never serrated |
| Panel width | Up to 1.25 m |
| Panel length | Up to 6 m |
| Materials | Q235B carbon steel · SS304 / SS316 stainless |
| Surface | Black or hot-dip galvanized (ASTM A123 / ISO 1461) |
| Layouts | All-serrated, all-plain, or mixed by zone — per drawing |
Materials & test documents
Every heat of Q235B, SS304 or SS316 enters production with its mill test certificate verified at goods-in — the first of our five QC stages. The serrated top changes the bar's surface, never its paper trail:
- Mill test certificate to EN 10204 Type 3.1
- Factory inspection report with every shipment
- Declaration of Conformity prepared per order destination
Bearing bar options explained → · Load tables & calculators →
Standards & compliance
What We Document — and What We Do Not Claim
ANSI / NAAMM MBG 531
Serrated and plain panels produced to MBG 531 reference practice, with weld inspection on our five-stage QC plan.
ASTM A123 / ISO 1461 HDG
Galvanized coating thickness checked by sampling on every galvanized batch before panels are released.
CE & SGS tested
Certified & tested, reports on request — steel, welds and coating documents you can verify.
One honest note: serration is geometry, not a certificate. We do not market slip-test coefficients or anti-slip ratings we do not hold — we describe the tooth profile, document the steel and the coating, and let your EHS team judge the fit. Standards hub, market by market →
Custom made
Custom Serrated Panels, Cut and Banded to Your Drawings
Send your drawing
Bar sections, spacing, zone plan — mark which areas get teeth and which stay plain. Or just a sketch; drawing review is free.
Quote within 24 hours
Itemized, FOB Tianjin as standard — EXW or CIF on request. Small trial orders welcome.
Samples in 5–7 days, production in 15–25
Working days after drawing confirmation, hot-dip galvanizing included. Installation drawings and fixing layout ship with the order.
Factory-direct quote
Get a Serrated Bar Grating Quote
Ask for a quote today — samples ready in 5–7 days. Send bar sections, spacing and your zone plan; an itemized quote lands within 24 hours.
- Serrated or plain bearing bars, any section from 20×3 to 100×8 mm
- Mixed layouts quoted zone by zone from one drawing
- DoC, MTC EN 10204 3.1 and inspection report with every order
Prefer to talk? WhatsApp us or sales@dtsteelladder.com
Request your quote
Five fields — we do the rest.
FAQ
Frequently Asked Questions
How does a serrated bearing bar work underfoot?
The tooth profile replaces the bar's flat top with a series of shallow edges. A wet or oily sole presses against many small shoulders instead of one continuous plane — that is the whole mechanism. We describe it as geometry and make no slip-test claims.
Which bars can be serrated — and can I mix layouts?
Any flat bar from 20×3 mm to 100×8 mm in our welded range can carry a serrated top, at 30, 40 or 60 mm centers. Cross bars stay plain. Mixed layouts — serrated panels for ramps and stairs, plain panels for dry zones — are quoted from your drawing in one order.
How fast can I get serrated bar grating samples?
Samples are ready in 5–7 working days, hot-dip galvanizing included, and mass production runs 15–25 working days after drawing confirmation. Ask for a quote today and we confirm both dates in the 24-hour reply.
